700H
Minimum energy, maximum performance
85<sup>m3/h</sup>
Maximum snow production
14.3 kW
Nominal power consumption
510 l/min
Max. water intake
700H
Minimum energy, maximum performance
85<sup>m3/h</sup>
Maximum snow production
14.3 kW
Nominal power consumption
510 l/min
Max. water intake
700H
Minimum energy, maximum performance
85<sup>m3/h</sup>
Maximum snow production
14.3 kW
Nominal power consumption
510 l/min
Max. water intake
Key elements of the 700H cannon
The 700H snow cannon combines high efficiency, energy efficiency and reliability, designed for modern ski resorts and recreational trails. With a maximum water intake of up to 510 l/min and low energy consumption (14.3 kW), this model achieves an impressive output of 88 m³ of snow per hour – ensuring the stability of the winter season even in adverse weather conditions.
Super-efficient nucleation technology
TwinC® nozzle
Hybrid water unit
Water ring
Mesh filter
Fan
Water ring
Mesh filter
Fan
Photo gallery of the 700H snow cannon
Product technical sheet
Standard equipment
- LED work light, 12/24 volts, 30 watts
- Warning lamp
- Oil-free compressor 1,5 kW
- Angled swivel connector with horizontal inlet with 2" female camlock
- Rubber water hose of mobile cannon, length. 1,9 m
- Removable operator panel integrated into the cannon
- Power cable 5x6 mm2, length 22 m
- Hydrant drive cable, length 22 m
- Operator panel cable, 1.8 m long
Accessory equipment
- SUPERWIRE or SUPERWAVE communication
- DV7 hydrant drive
- DV7 hydrant drive
- SNOWFLEX hose with camlock ends 2", 20 m
- Foot or wheeled chassis
Technical data
Number of water sections
5
Number of nucleation sections
1
Number of water jets
96
Number of nucleation nozzles
6
Working pressure of water
8-40 bar
Water intake for
510 l/min
Water intake for
88m3/h
Weight
Cannon without chassis
600 kg
Cannon on a technological base
620 kg
Foot chassis complete
160 kg
Wheeled chassis
270 kg
Other
Fan speed
1450 rpm
Range of density of snow produced
330-870 g/l
Number of degrees of snow quality
7
Adjustment range of the tube angle
0°-45°
Range of rotation
360°
Automatic oscillation with angle adjustment range
15°-120°
Electrical
Nominal power consumption
14.3 kW
Water ring heating
1.8 kW
Oil-free compressor
1.5 kW
Fan motor
11 kW
Download the catalog
Check out the full specifications of the snow cannons. Download the catalog in PDF format – ready to print or share.
Frequently asked questions
Here are answers to the most frequently asked questions about the snow cannon.
How does the cannon work?
The snow cannon works by spraying water under high pressure. This turns the water into fine ice crystals. This process occurs under the right atmospheric conditions.
What are its advantages?
A snow cannon provides excellent quality snow that is durable and dense. It also makes it possible to produce snow in conditions where natural precipitation is insufficient. It is an ideal solution for ski resorts.
Is it easy to use?
Yes, the snow cannon is designed with ease of use in mind. It has an intuitive control panel that allows easy adjustment of settings. As a result, anyone can use it without specialized training.
What are the operating costs?
The cost of operating a snow cannon varies and depends on many factors. However, it is worth noting that this investment brings long-term savings. Thanks to the efficiency of snow production, you can minimize the costs associated with its maintenance.
What are the requirements?
In order for a snow cannon to work effectively, the right weather conditions are needed. The temperature should be below freezing and the humidity at the right level. It is also good to have access to water and electricity.
