MP200 mobile pump
With the MP200 mobile pump, snowmaking in hard-to-reach places becomes possible. This is an ideal solution for small ski resorts and stations where the terrain prevents the installation of traditional snowmaking systems. The 15, 22 or 30 kW pump will handle up to four snow cannons simultaneously. The MP200’s compact size makes it easy to transport, and in combination with SUPERSNOW mobile snow cannons it will be great for cross-country skiing trails, for example.
Rotor heating system
In the design of the impeller housing, we used heating elements that heat the impeller before starting the pump.
Dewatering systems
The high-pressure section is equipped with an automatic drainage system.
Rotor heating system
In the design of the impeller housing, we used heating elements that heat the impeller before starting the pump.
Dewatering systems
The high-pressure section is equipped with an automatic drainage system.
Photo Gallery
Technical details of mobile pumps
Dimensions
Transport dimensions of the pump
15 kW
22 kW
30 kW
height
1930 mm
2100 mm
1950 mm
width
2150 mm
2150 mm
2150 mm
length
2390 mm
2390 mm
2390 mm
Standard equipment
- LED work light, 12/24 volts, 30 watts
- Warning lamp
- Oil-free compressor 1,5 kW
- Angled swivel connector with horizontal inlet with 2" female camlock
- Rubber water hose of the mobile cannon, length 1.9 m
- Removable operator panel integrated into the cannon
- Power cable 5x6 mm2, length 22 m
- Hydrant drive cable, length 22 m
- Operator panel cable, 1.8 m long
Accessory equipment
- SUPERWIRE or SUPERWAVE communication
- DV7 hydrant drive
- DV7 hydrant drive
- SNOWFLEX hose with camlock ends 2", 20 m
- Foot or wheeled chassis
Technical data
Download power
15 kW
22 kW
30 kW
Power supply
400 V
(± 10%) 50 Hz
400 V
(± 10%) 50 Hz
400 V
(± 10%) 50 Hz
Pump capacity
24m3/h
42 m3/h
52 m3/h
Maximum lift height
216,2 m
236 m
198 m
Weight of pump on wheeled chassis
430 kg
580 kg
615 kg
